Specifications
Length Overall	27'0"	8.23 m
Waterline Length	23'7"	7.18 m
Beam	9'11"	3.02 m
Displacement (Shoal)	7,656 lb	3,476 kg
Displacement (Deep)	7,505 lb	3,407 kg
Draft (Shoal)	3'6"	1.05 m
Draft (Deep)	5'0"	1.52 m
Mast Height (Std)	39'9"	12.12 m
Mast Height (Furling)	43'8"	13.31 m
Sail Area (Std)	386 ft2	35.86 m2
Sail Area (Furling)	369 ft2	34.28 m2
I	27'0"	8.24 m
J	8'11"	2.72 m
P (Std)	30'4"	9.25 m
P (Furling)	34'5"	10.49 m
E (Std)	11'8"	3.55 m
E (Furling)	14'4"	4.37 m
Fuel Capacity	12 gal	45 l
Water Capacity	20 gal	75.70 l
Hold Tank Capacity	10 gal	37.85 l
Headroom	6'2"	1.90 m
Maximum Power	14 hp	10.4 kw
CE Classification	B	B

RIGGING
>	Anodized B & R Fractional Rig
>	Boom Vang
>	Dual Jiffy Reefs System
>	Internal Halyards Led to Cockpit
>	Large Roach Main w/Battens & Flaking System
>	Mainsail Cover
>	110% Jib w/Roller Furling System
>	Mainsheet Purchase System
>	(2) Cabin-Mounted #16 Rigging Winches
>	Adjustable Jib Lead Tracks
>	(2) Sets Triple Line Stoppers
DECK/HULL
>	Anchor Roller
>	Anchor Well w/Space for Rode/Chain
>	Balanced Spade Rudder
>	Bronze Through-Hulls Fittings Below Waterline
>	Single Lifeline w/Dual Gates
>	Fiberglass Hull w/Structural Grid
>	Reinforcement and NPG Blister-Resistant Gelcoat
>	Integrated Swim Platform
>	Reinforced Fiberglass Deck w/MaxGuard¨ UV-Inhibited Gelcoat & Molded-In Non-Skid
>	Keel — Antimonious Lead Keel, Shoal Draft
>	Sliding Companionway Hatch
>	Stainless Steel Bow Pulpit, Stern Rail Seats, Lifeline Stanchions, and Handrails
>	Through-Bolted Hull to Deck Joint with Wraparound PVC Rubrail
COCKPIT
>	Cockpit Storage Locker
>	Integrated Wheel Console Includes: Wheel Steering System, Single Lever Engine Control, Wheel Brake, Lighted Compass, Instrument Pod & Stainless Steel Wheel Guard
>	Walk-Through Transom w/Swim Platform
>	Removable Helm Seat
>	Telescoping Swim Ladder
>	Manual Bilge Pump
CABIN
>	Solid Hardwood Trim
>	Insulated Hull Liner
>	6'2" Headroom
>	Whisper/Composite Headliner
>	Convertible V-Berth/Storage Area
>	Deck Hatch
>	Storage Cabinet
>	(4) 12V Lighting Fixtures
>	Fully Enclosed Head Compartment w/Portable MSD, Vanity, Opening Port & Hanging Bar
>	Private Aft Cabin w/Double Berth, Hanging Locker, Opening Port, Opening Ventilation Hatch & 12V Lighting
>	Gas Shock-Assisted Engine Access
SYSTEMS/ELECTRONICS
>	12V DC Electrical System w/Battery Switch & Breaker Panel
>	Navigation Light Package
>	Manual Water Pump System
>	Cabin Lighting
>	Electric Automatic Bilge Pump
>	20 (75 Liters) Gallon Fresh Water Capacity
>	15 (57 Liters) Gallon Fuel Capacity
GALLEY
>	Single Stainless Steel Sink Basin
>	Laminate Counter Top
>	Solid Teak Hardwood Trim
>	Dishware w/Custom Hanging Storage Bag
>	In-Counter Waste Bin
GENERAL SAFETY GROUP
>	Emergency Tiller
>	Carbon Monoxide Alarms
>	Smoke Detectors

CRUISING PACKAGE ADDITIONAL STANDARD EQUIPMENT
>	Upgrade to 14HP Yanmar Diesel Saildrive
SYSTEMS/ELECTRONICS
>	220V AC System w/Circuit Protection, Power Cord, Isolation Transformer & Interior Outlets
>	Battery Charger
>	Water Heater
>	Pressure Water System
CABIN
>	Everwear¨ Laminate Cabin Sole
>	Dinette Table w/Hinging Leaf
>	Shower & Sump Pump in Head
>	Marine Head with Holding Tank and Overboard Discharge, in lieu of Portable MSD
GALLEY
>	220V Outlet
>	12V/40 Quart Thermo - Electric Cooler In Custom Slide-Out Compartment
>	Two Burner Non-Pressurized Alchohol Stove

ADDITIONAL OPTIONAL EQUIPMENT
>	In-Mast Furling
>	Self Tailing Winches at Helm for Jib Sheeting
>	Mainsheet Traveler
>	Marine Head w/Holding Tank & Macerator Pump
>	Solid Boom Vang
>	Bimini Top
>	Spray Hood
>	Spinnaker Gear
>	Deep Draft Keel
>	Twin Keels (cast iron)
>	Epoxy Barrier Coat
>	Bottom Paint
>	VHF Radio with DSC
>	Raymarine Knot/Depth ST40
>	Raymarine Windmachine ST60
>	Raymarine Autopilot 4000+
>	Accordian Window Shades
>	FM-200 Engine Fire Extinguisher with Engine Shutdown
>	High Water Bilge Alarm System and Additional Pump

*Hunter Marine reserves the right to modify or change, without notice, any materials, specifications, equipment and/or accessories. All measurements are approximate. Standard equipment may vary for products sold outside the United States.
